Dinosaur D
| size: | |
|---|---|
| resolution: | |
| brightness: | |
| refresh rate: | |
| viewing angle: | |
| lifespan: | |
| power supply: | |
| Availability: | |
| Quantity: | |
Key features include seamless wireless screen mirroring, built-in educational software tools, and compatibility with a wide range of teaching applications. Its all-in-one design eliminates the need for external projectors or complex setups, offering plug-and-play simplicity and easy mobility between rooms.
Durable, intuitive, and engineered to foster engagement, this Interactive Whiteboard is the ultimate tool for creating an immersive, collaborative, and future-ready smart classroom. Elevate interaction, simplify instruction, and inspire every student.
Key features include seamless wireless screen mirroring, built-in educational software tools, and compatibility with a wide range of teaching applications. Its all-in-one design eliminates the need for external projectors or complex setups, offering plug-and-play simplicity and easy mobility between rooms.
Durable, intuitive, and engineered to foster engagement, this Interactive Whiteboard is the ultimate tool for creating an immersive, collaborative, and future-ready smart classroom. Elevate interaction, simplify instruction, and inspire every student.
| Screen panel specification | Diagonal Size | 65 inch | ||||
| Effective Display Area | 1429（H）×805（V）mm | |||||
| Display Ratio | 16:9 | |||||
| Brightness | 350cd/㎡ | |||||
| refresh rate | 60Hz | |||||
| Contrast Ratio | 5000:1 | |||||
| Backlight Type | DLED | |||||
| Viewing Angle | 178°(V)/178°(H) | |||||
| Lifespan | 50000 hours | |||||
| Resolution | 3840（H) X 2160(V) | |||||
| Front interface | Input port | USB3.0*1 | ||||
| USB2.0*2 | ||||||
| Whole machine interface | Input port | RJ45*1 | ||||
| TOUCH USB*1 | ||||||
| USB 3.0*1 | ||||||
| USB 2.0*1 | ||||||
| RS232*1 | ||||||
| TOUCH USB(HDMI) *1 | ||||||
| HDMI 1*1 | ||||||
| AV IN：×2 | ||||||
| Other port | SPDIF OUT*1 | |||||
| AV OUT：×1 | ||||||
| Earphone*1 | ||||||
| Front button | Power Button On/Off, Volume +, Volume -, Eye protection, Screen recording, Home, Settings, Touch switch | |||||
| Touch screen | Touch technology | Multiple Infrared scanning technology | ||||
| Touch type | 20 point touch | |||||
| Drive Mode | Automatically recognized by the system, no need to drive | |||||
| Front frame glass | Physical tempered grade 9 explosion-proof glass/anti-glare explosion-proof grade 9 tempered glass | |||||
| writing style | Finger, touch pen or other non-transparent objects ≥2mm (supports full-screen writing with dual fine pens) | |||||
| Touch resolution | 32767*32767 | |||||
| way of communication | USB 2.0/USB 3.0 | |||||
| Operating temperature | -10~+50 ℃ | |||||
| Single finger response speed | ＜8ms | |||||
| Touch Accuracy | ±1mm | |||||
| Touch Time | the number of theoretical times is unlimited | |||||
| support system | windowsXP/7/8/10，Android，MacOS，Linux | |||||
| Built-in camera | camera | 48 million autofocus camera | ||||
| array microphone | Eight array voice microphone | |||||
| Accessories | Accessory box | 1pcs | ||||
| Power cord-National standard 1.8M | 1pcs | |||||
| Certificate of Conformity (neutral) | 1pcs | |||||
| Warranty card (neutral) | 1pcs | |||||
| Remote control (without battery) | 1pcs | |||||
| Touch pen (magnetic) | 2pcs | |||||
| Wall mounting bracket | 1pcs | |||||
| Power consumption | Power consumption of the whole machine (excluding OPS) | ≤260W | ||||
| OPS consumption | ≤80W | |||||
| Standby consumption | ≤0.5W | |||||
| Power supply | 100-240V, 50/60Hz | |||||
| Stereo power | 10W/8 ohm x 2 speakers | |||||
| Working environment | Operating temperature | 0-40℃ | ||||
| Operating humidity | 10%~90% RH | |||||
| Storage temperature | -20~60℃ | |||||
| Storage humidity | 10%~90% RH | |||||
| VESA bracket hole location(mm) | 400(V)×500(H) | |||||
| Delivery Terms | Payment term | alibaba trade assurance contract;T/T payment or Paypal, if paypal customer should burder the bank handing fee | ||||
| delivery time | within 10 working day ( from the day calculating when the payment arrived in our bank account. | |||||
| Warranty | 1 year | |||||
| Screen panel specification | Diagonal Size | 65 inch | ||||
| Effective Display Area | 1429（H）×805（V）mm | |||||
| Display Ratio | 16:9 | |||||
| Brightness | 350cd/㎡ | |||||
| refresh rate | 60Hz | |||||
| Contrast Ratio | 5000:1 | |||||
| Backlight Type | DLED | |||||
| Viewing Angle | 178°(V)/178°(H) | |||||
| Lifespan | 50000 hours | |||||
| Resolution | 3840（H) X 2160(V) | |||||
| Front interface | Input port | USB3.0*1 | ||||
| USB2.0*2 | ||||||
| Whole machine interface | Input port | RJ45*1 | ||||
| TOUCH USB*1 | ||||||
| USB 3.0*1 | ||||||
| USB 2.0*1 | ||||||
| RS232*1 | ||||||
| TOUCH USB(HDMI) *1 | ||||||
| HDMI 1*1 | ||||||
| AV IN：×2 | ||||||
| Other port | SPDIF OUT*1 | |||||
| AV OUT：×1 | ||||||
| Earphone*1 | ||||||
| Front button | Power Button On/Off, Volume +, Volume -, Eye protection, Screen recording, Home, Settings, Touch switch | |||||
| Touch screen | Touch technology | Multiple Infrared scanning technology | ||||
| Touch type | 20 point touch | |||||
| Drive Mode | Automatically recognized by the system, no need to drive | |||||
| Front frame glass | Physical tempered grade 9 explosion-proof glass/anti-glare explosion-proof grade 9 tempered glass | |||||
| writing style | Finger, touch pen or other non-transparent objects ≥2mm (supports full-screen writing with dual fine pens) | |||||
| Touch resolution | 32767*32767 | |||||
| way of communication | USB 2.0/USB 3.0 | |||||
| Operating temperature | -10~+50 ℃ | |||||
| Single finger response speed | ＜8ms | |||||
| Touch Accuracy | ±1mm | |||||
| Touch Time | the number of theoretical times is unlimited | |||||
| support system | windowsXP/7/8/10，Android，MacOS，Linux | |||||
| Built-in camera | camera | 48 million autofocus camera | ||||
| array microphone | Eight array voice microphone | |||||
| Accessories | Accessory box | 1pcs | ||||
| Power cord-National standard 1.8M | 1pcs | |||||
| Certificate of Conformity (neutral) | 1pcs | |||||
| Warranty card (neutral) | 1pcs | |||||
| Remote control (without battery) | 1pcs | |||||
| Touch pen (magnetic) | 2pcs | |||||
| Wall mounting bracket | 1pcs | |||||
| Power consumption | Power consumption of the whole machine (excluding OPS) | ≤260W | ||||
| OPS consumption | ≤80W | |||||
| Standby consumption | ≤0.5W | |||||
| Power supply | 100-240V, 50/60Hz | |||||
| Stereo power | 10W/8 ohm x 2 speakers | |||||
| Working environment | Operating temperature | 0-40℃ | ||||
| Operating humidity | 10%~90% RH | |||||
| Storage temperature | -20~60℃ | |||||
| Storage humidity | 10%~90% RH | |||||
| VESA bracket hole location(mm) | 400(V)×500(H) | |||||
| Delivery Terms | Payment term | alibaba trade assurance contract;T/T payment or Paypal, if paypal customer should burder the bank handing fee | ||||
| delivery time | within 10 working day ( from the day calculating when the payment arrived in our bank account. | |||||
| Warranty | 1 year | |||||
Collaborative Classrooms: Enables multi-student interaction with 20-point touch technology, perfect for group activities and brainstorming sessions.
Hybrid Learning: Supports wireless screen mirroring from student devices (iOS/Android/Windows) for seamless blended learning experiences.
STEM Education: Interactive 3D models and coding platforms enhance science, technology, and math lessons with hands-on learning.
Language Labs: Real-time translation tools and multilingual interfaces support ESL (English as a Second Language) programs.
Special Needs Education: Adjustable touch sensitivity and accessibility features accommodate diverse learning requirements.
Dynamic Presentations: Annotate directly on documents during meetings with finger or stylus input.
Video Conferencing: Integrated with Zoom, Teams, and Webex for interactive remote collaboration.
Design & Training: Architects and engineers can manipulate CAD models, while HR teams conduct interactive onboarding sessions.
Interactive Patient Education: Doctors illustrate treatment plans using zoomable anatomy diagrams.
Surgical Planning: Medical students practice procedures on high-resolution 3D models.
Emergency Response: Tactile command center displays for real-time crisis management.
Public Kiosks: Sunlight-readable screens provide wayfinding and municipal information.
Digital Showrooms: Customers interact with product catalogs via touchscreen.
Self-Service Terminals: Hotels and restaurants use for check-in/ordering systems.
Collaborative Classrooms: Enables multi-student interaction with 20-point touch technology, perfect for group activities and brainstorming sessions.
Hybrid Learning: Supports wireless screen mirroring from student devices (iOS/Android/Windows) for seamless blended learning experiences.
STEM Education: Interactive 3D models and coding platforms enhance science, technology, and math lessons with hands-on learning.
Language Labs: Real-time translation tools and multilingual interfaces support ESL (English as a Second Language) programs.
Special Needs Education: Adjustable touch sensitivity and accessibility features accommodate diverse learning requirements.
Dynamic Presentations: Annotate directly on documents during meetings with finger or stylus input.
Video Conferencing: Integrated with Zoom, Teams, and Webex for interactive remote collaboration.
Design & Training: Architects and engineers can manipulate CAD models, while HR teams conduct interactive onboarding sessions.
Interactive Patient Education: Doctors illustrate treatment plans using zoomable anatomy diagrams.
Surgical Planning: Medical students practice procedures on high-resolution 3D models.
Emergency Response: Tactile command center displays for real-time crisis management.
Public Kiosks: Sunlight-readable screens provide wayfinding and municipal information.
Digital Showrooms: Customers interact with product catalogs via touchscreen.
Self-Service Terminals: Hotels and restaurants use for check-in/ordering systems.
1. Q: What sizes are available for the All-in-One Interactive Smart Board?
A: The board is available in four versatile sizes to suit different classroom spaces: 55 inches, 65 inches, 75 inches, and 86 inches.
2. Q: Is the screen touch-sensitive, and how many touch points does it support?
A: Yes, it features a highly responsive finger-touch LCD screen that typically supports 10 or more simultaneous touch points, enabling seamless multi-user interaction.
3. Q: Is the device truly all-in-one? What components are included?
A: Yes, it is an integrated solution that includes the high-definition LCD display, an Android/Windows operating system (varies by model), built-in speakers, touch sensors, and often pre-installed teaching software—all in a single unit.
4. Q: Can the Smart Board be moved easily between classrooms?
A: Yes, it is designed with portability in mind. Many models come with a sturdy mobile stand or can be mounted on a rolling cart for easy relocation.
5. Q: What operating system does it run on, and what teaching software is included?
A: Depending on the model, it may run on Android, Windows, or a dual OS. It often comes with preloaded whiteboard software, screen mirroring apps, and tools for annotation, recording, and lesson creation.
6. Q: How do I connect external devices like a laptop, document camera, or tablet?
A: It offers multiple connectivity options, including HDMI, USB, VGA, and wireless screen mirroring via Miracast, AirPlay, or dedicated casting apps.
7. Q: Is internet access required for all features?
A: Basic functions like touch writing and annotation work offline. Features like screen mirroring, accessing online resources, and software updates require Wi-Fi or wired internet.
8. Q: What type of maintenance does the Smart Board require?
A: Regular cleaning of the screen with a soft, dry microfiber cloth is recommended. The system is designed for durability with minimal hardware maintenance required under normal use.
9. Q: Can students interact with the board at the same time?
A: Absolutely. The multi-touch capability allows multiple students to write, draw, or interact with content simultaneously, making group activities highly engaging.
10. Q: Is training provided for teachers to use the board effectively?
A: Many suppliers offer user manuals, video tutorials, and live online training sessions. Some packages also include on-site or virtual teacher training workshops.
1. Q: What sizes are available for the All-in-One Interactive Smart Board?
A: The board is available in four versatile sizes to suit different classroom spaces: 55 inches, 65 inches, 75 inches, and 86 inches.
2. Q: Is the screen touch-sensitive, and how many touch points does it support?
A: Yes, it features a highly responsive finger-touch LCD screen that typically supports 10 or more simultaneous touch points, enabling seamless multi-user interaction.
3. Q: Is the device truly all-in-one? What components are included?
A: Yes, it is an integrated solution that includes the high-definition LCD display, an Android/Windows operating system (varies by model), built-in speakers, touch sensors, and often pre-installed teaching software—all in a single unit.
4. Q: Can the Smart Board be moved easily between classrooms?
A: Yes, it is designed with portability in mind. Many models come with a sturdy mobile stand or can be mounted on a rolling cart for easy relocation.
5. Q: What operating system does it run on, and what teaching software is included?
A: Depending on the model, it may run on Android, Windows, or a dual OS. It often comes with preloaded whiteboard software, screen mirroring apps, and tools for annotation, recording, and lesson creation.
6. Q: How do I connect external devices like a laptop, document camera, or tablet?
A: It offers multiple connectivity options, including HDMI, USB, VGA, and wireless screen mirroring via Miracast, AirPlay, or dedicated casting apps.
7. Q: Is internet access required for all features?
A: Basic functions like touch writing and annotation work offline. Features like screen mirroring, accessing online resources, and software updates require Wi-Fi or wired internet.
8. Q: What type of maintenance does the Smart Board require?
A: Regular cleaning of the screen with a soft, dry microfiber cloth is recommended. The system is designed for durability with minimal hardware maintenance required under normal use.
9. Q: Can students interact with the board at the same time?
A: Absolutely. The multi-touch capability allows multiple students to write, draw, or interact with content simultaneously, making group activities highly engaging.
10. Q: Is training provided for teachers to use the board effectively?
A: Many suppliers offer user manuals, video tutorials, and live online training sessions. Some packages also include on-site or virtual teacher training workshops.
