retail bill android barcode reader all in one touch payment terminal order printer scanner self-service kiosk

retail bill android barcode reader all in one touch payment terminal order printer scanner self-service kiosk

Available in 21.5”, 24”, and 32” screen sizes, the kiosk offers ultimate flexibility with floor-stand, desktop, and wall-mount configurations to fit any space—from retail floors to restaurant counters. Its core strength lies in platform versatility, supporting Android, Windows, and Linux operating systems for easy integration with your existing software.
Beyond the intuitive touchscreen, it is a true all-in-one workhorse. The built-in barcode scanner enables quick product lookups and inventory management, while the integrated order ticket printer provides instant receipts or tickets. Crucially, the system can be equipped with a secure touch payment terminal, making it a complete point-of-sale solution for self-service checkouts, ordering, and bill payment.

Simplify your business, reduce wait times, and empower your customers with our feature-rich, future-proof All-in-One Self-Service Kiosk

Brand:
Dinosaur D

size:	21.5 24 32 inch options
installation method:	floor stand ,desktop,or wall-mount options
resolution:	2K
cusomization:	printer,QR scanner,NFC,pos holder,camera
viewing angle:	178°/178°(H/V)
lifespan:	more than 50000h
response time:	6ms
Availability:

Quantity:



Inquire Add to Basket

Our intelligent self-service kiosk is a complete business solution that combines payment processing, order management, and customer interaction in one sleek unit. Available in three screen sizes (21.5", 24", or 32") with full HD touch displays, this versatile system adapts to any commercial environment through multiple mounting options - free-standing floor stand, space-saving desktop, or wall-mounted installation.

Key Features:

Multi system options: android ,window or Linux operating systems
All-in-One Functionality: Integrated barcode scanner, printer, NFC, pos holder ,camera
Flexible Deployment: Three installation styles to match your space requirements
Customize backplate: add logo,text,or patterns you want
Modual design: cusotmization options can be dismantled according to your requirements

self-service kiosk 1 self-service kiosk 2 self-service kiosk 3 self-service kiosk 4 self-service kiosk 5 self-service kiosk 6 self-service kiosk 7 self-service kiosk 8 self-service kiosk 9 self-service kiosk 10 self-service kiosk 11

printer	Printing method	thermal line dot printing
	Print speed	Max:180mm/s
	Resolution	203dpi(8dots/mm)
	Print width	72mm
	Cutter	both full cut and partial cut are supported
Qr scanner	Image sensor	640（H） X 480（V）CMOS
	Light source	white fill light / colored light indicator
	Readable Code System	QR Code: QR Code, PDF417, DataMatrix (ECC200)
		EAN13, EAN UPC-E0, UPC-E1, Code128, Code39, Code93, CodaBar, Interleaved 2 of 5, Industrial 25, Matrix 2 of 5, Code11, MSI, RSS-14, Limited RSS, Expanded RSS
	Reading perspective	rotate 360°, tilt ±60°, deflect ±60°
	Understanding depth of field	EAN-132~11.0cm 13mil、Code-128 2.5 ~ 13.0cm （15mil ）
	Recognition accuracy	1D barcode: ≥5 mil, 2D barcode: ≥10 mil
NFC	External Interface	serial port (TTL level/RS232 level selectable)
	Support card	contactless Card: Mifare One S50/S70, Mifare UltraLight NTAG213/215/216
	Sensing distance	type A Card: 0 ~ 5.0 cm Test Conditions: 1) Use a standard size card of 85.6mm × 54mm; 2) Use an integrated antenna.
Camera	Optical dimensions	1/2.7”inch COMS sensor
	Sensor resolution	1920 (H) x 1080 (V)
	Maximum frame rate	30fps@1080P
screen panel specification	Screen size	24 inch BOE or Star A new full lcd screen
	Resolution	1920*1080（2k）
	Brightness	350cd/m2
	Number of Color	16.7M
	Response time	6ms
	Contrast	2000：1
	View angle	178°/178°(H/V)
	Life Time	> 50000 (hours)
	OSD Language	English, Chinese, French, German, Italian, Spanish,Arabic etc.
capacitive touch parameter	Touch technology	10 point capacitive touch
	Sensing object	fingers, stylus
	Response time	3ms
	Sensing accuracy	±1.5mm
	Touch lifespan	over 60 million times, the touch cursor does not drift
	Touch resolution	4096*4096
Power	Input Voltage	AC100-240v 50/60HZ
	Horn	2×2W(8Ω)
	Standby power	≤1W
	Power Consumption	≤50W
	Storage temparature	(-20℃ -- 60 ℃)
	Operation temparature	(0℃-- 50 ℃)
	Operation humidity	(10 -- 90% )
Appearance design	aluminum alloy frame, high-quality sheet metal
Casing color	black

1. Q: What screen sizes are available for the self-service kiosk?
A: The kiosk is available in three versatile screen sizes to suit different spatial and application needs: 21.5-inch, 24-inch, and 32-inch.

2. Q: How can the kiosk be installed?
A: For maximum flexibility, our kiosk supports multiple installation styles. You can set it up as a free-standing floor model, a compact desktop unit, or a space-saving wall-mounted terminal.

3. Q: Which operating systems are compatible?
A: The kiosk is designed for broad software compatibility and supports the Android, Windows, and Linux operating systems.

4. Q: Does the kiosk have a built-in barcode scanner?
A: Yes, it comes with an integrated barcode reader, making it ideal for retail self-checkout, inventory lookup, and ticket validation.

5. Q: Is the touchscreen the only input method?
A: The primary interface is the intuitive all-in-one touch screen. For secure transactions, it can also be equipped with an integrated touch payment terminal.

6. Q: Can this kiosk process payments?
A: Yes, it can be configured as a complete touch payment terminal, allowing customers to securely complete self-service transactions.

7. Q: Does the kiosk print receipts or tickets?
A: Absolutely. The kiosk includes a built-in order ticket printer, enabling it to provide physical receipts, tickets, or order slips on demand.

8. Q: What is the main function of this all-in-one device?
A: It is a multifunctional self-service kiosk that integrates a computer, touchscreen, barcode reader, payment terminal, and printer into one unit, automating tasks like ordering, payments, and check-ins.

9. Q: What industries is this kiosk suited for?
A: It is perfect for a wide range of industries including retail (self-checkout), hospitality (self-ordering), transportation (ticketing), and entertainment (event registration).

10. Q: What makes this kiosk an "all-in-one" solution?
A: It combines the computer, touch display, and critical peripherals like a barcode scanner, payment terminal, and ticket printer into a single, streamlined device, reducing clutter and simplifying setup.
