Dinosaur D
| size: | |
|---|---|
| tempered glass thickness: | |
| resolution: | |
| brightnees: | |
| protection level: | |
| lifespan: | |
| Input voltage: | |
| Availability: | |
| Quantity: | |
Superior Outdoor Visibility: Featuring a high-brightness, sun-readable LCD display, content remains vivid, clear, and easily viewable even under direct sunlight, ensuring your message is always seen.
Built for All Elements: With a true IP65 (weather-proof/waterproof) rating, this kiosk is completely protected against dust ingress and water jets. It is designed to perform reliably through rain, heat, cold, and harsh environmental conditions.
Superior Outdoor Visibility: Featuring a high-brightness, sun-readable LCD display, content remains vivid, clear, and easily viewable even under direct sunlight, ensuring your message is always seen.
Built for All Elements: With a true IP65 (weather-proof/waterproof) rating, this kiosk is completely protected against dust ingress and water jets. It is designed to perform reliably through rain, heat, cold, and harsh environmental conditions.
| structure | product dimension | 690mm(L)*400mm(W)*1800mm(H) | ||||
| product net weight | 80KG | |||||
| protect level | outdoor IP65 | |||||
| casing color | black | |||||
| shell material | Hot-dip galvanized steel plate T=1.5 + outdoor double-sided spraying outdoor powder | |||||
| glass | 6 mm tempered glass with light transmittance of more than 98%. | |||||
| Security | three-level door lock protection, hidden screw design, electronic magnetic lock | |||||
| dissipation system | The fan speed can be automatically adjusted according to the operating temperature, with heating function | |||||
| brightness control | Automatic photosensitive probe - automatically recognizes the surrounding environment and automatically adjusts the brightness of the screenm | |||||
| interface | USB, VGA output, HDMI output, AV input, SD card slot( supports up to 32GB), microphone, Clock battery holder | |||||
| camera optional | 500W pixels | |||||
| loudspeaker | 8Ω10W * 2 | |||||
| protection | waterproof | three layers of composite sealing rubber strip | ||||
| anti-electric leakage | 3C certified brand leakage protector | |||||
| anti-thunder | unique lightning protection device | |||||
| dust proof | internal high air volume filter device | |||||
| anti-explosion | 6MM tempered glass, explosion-proof, UV proof, low reflection, transmittance of more than 97% | |||||
| Anti-glare glass optional | 6mm AR anti-reflection glass. AR coating is adopted | |||||
| anti-rust | galvanized steel sheet and outdoor double-sided spraying outdoor powder | |||||
| screen panel specification | screen size | 43 inch LCD screen panel | ||||
| display area | 530mm*942mm | |||||
| resolution | 1920*1080 | |||||
| view angles | 178°（H）/178°（V） | |||||
| Contrast | 3500:1 | |||||
| Brightness | 2500cd/㎡ | |||||
| color | 16.7 M | |||||
| Display Scale | 16 : 9 | |||||
| lifespan | >50000 hours | |||||
| refresh rate | 60Hz | |||||
| respond time | 6ms | |||||
| parameter of touch | touch way | fingers | ||||
| effective touch recognition | ≥5mm | |||||
| touch accuracy | ±5mm | |||||
| touch point | 10 point | |||||
| first point response time | ≤10ms | |||||
| Fan cooling system | intelligent air cooling system for heat dissipation | |||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | ||||||
| The LCD screen does not blacken at -40 °C to 55°C | ||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | ||||||
| patented cooling system | ||||||
| Ensure that the LCD screen is not blackened in direct sunlight | ||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | ||||||
| intelligent control fan wind speed | ||||||
| product test | IP65 test | |||||
| high temperature aging | ||||||
| low temperature aging | ||||||
| simulated sunlight test | ||||||
| water proof test | ||||||
| surface treatment | wash | all parts of the sheet metal are cleaned in an acidic and alkaline manner | ||||
| anti-rust | Spray anti-rust paint | |||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | |||||
| Power | Input voltage | AC110-240V,50/60Hz | ||||
| power consumption | ≤300w | |||||
| working environment | temperature control | fan cooling (air cooling optional) | ||||
| operation temperature | -20°C to +50°C | |||||
| storage temperarure | -20°C to +60°C | |||||
| operation humidity | 5% to 90% | |||||
| quality standard | ISO9001 | |||||
| environmental protection standard | Meet international environmental standards | |||||
| power management | Meets VESA DPMS standard | |||||
| structure | product dimension | 690mm(L)*400mm(W)*1800mm(H) | ||||
| product net weight | 80KG | |||||
| protect level | outdoor IP65 | |||||
| casing color | black | |||||
| shell material | Hot-dip galvanized steel plate T=1.5 + outdoor double-sided spraying outdoor powder | |||||
| glass | 6 mm tempered glass with light transmittance of more than 98%. | |||||
| Security | three-level door lock protection, hidden screw design, electronic magnetic lock | |||||
| dissipation system | The fan speed can be automatically adjusted according to the operating temperature, with heating function | |||||
| brightness control | Automatic photosensitive probe - automatically recognizes the surrounding environment and automatically adjusts the brightness of the screenm | |||||
| interface | USB, VGA output, HDMI output, AV input, SD card slot( supports up to 32GB), microphone, Clock battery holder | |||||
| camera optional | 500W pixels | |||||
| loudspeaker | 8Ω10W * 2 | |||||
| protection | waterproof | three layers of composite sealing rubber strip | ||||
| anti-electric leakage | 3C certified brand leakage protector | |||||
| anti-thunder | unique lightning protection device | |||||
| dust proof | internal high air volume filter device | |||||
| anti-explosion | 6MM tempered glass, explosion-proof, UV proof, low reflection, transmittance of more than 97% | |||||
| Anti-glare glass optional | 6mm AR anti-reflection glass. AR coating is adopted | |||||
| anti-rust | galvanized steel sheet and outdoor double-sided spraying outdoor powder | |||||
| screen panel specification | screen size | 43 inch LCD screen panel | ||||
| display area | 530mm*942mm | |||||
| resolution | 1920*1080 | |||||
| view angles | 178°（H）/178°（V） | |||||
| Contrast | 3500:1 | |||||
| Brightness | 2500cd/㎡ | |||||
| color | 16.7 M | |||||
| Display Scale | 16 : 9 | |||||
| lifespan | >50000 hours | |||||
| refresh rate | 60Hz | |||||
| respond time | 6ms | |||||
| parameter of touch | touch way | fingers | ||||
| effective touch recognition | ≥5mm | |||||
| touch accuracy | ±5mm | |||||
| touch point | 10 point | |||||
| first point response time | ≤10ms | |||||
| Fan cooling system | intelligent air cooling system for heat dissipation | |||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | ||||||
| The LCD screen does not blacken at -40 °C to 55°C | ||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | ||||||
| patented cooling system | ||||||
| Ensure that the LCD screen is not blackened in direct sunlight | ||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | ||||||
| intelligent control fan wind speed | ||||||
| product test | IP65 test | |||||
| high temperature aging | ||||||
| low temperature aging | ||||||
| simulated sunlight test | ||||||
| water proof test | ||||||
| surface treatment | wash | all parts of the sheet metal are cleaned in an acidic and alkaline manner | ||||
| anti-rust | Spray anti-rust paint | |||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | |||||
| Power | Input voltage | AC110-240V,50/60Hz | ||||
| power consumption | ≤300w | |||||
| working environment | temperature control | fan cooling (air cooling optional) | ||||
| operation temperature | -20°C to +50°C | |||||
| storage temperarure | -20°C to +60°C | |||||
| operation humidity | 5% to 90% | |||||
| quality standard | ISO9001 | |||||
| environmental protection standard | Meet international environmental standards | |||||
| power management | Meets VESA DPMS standard | |||||
✔ Bus/Train Stations
Real-time departure boards with touchscreen route planning
Emergency alert broadcasts (weather/security)
Contactless NFC ticket top-up stations
✔ EV Charging Hubs
Dynamic pricing/payment screens
Charging status animations
Nearby amenity directories
✔ Shopping Mall Entrances
AI-powered facial recognition ads (gender/age targeting)
Interactive store directories with AR navigation
Limited-time promo countdown timers
✔ Drive-Thru & QSR
Ultra-bright menu boards (2500nit visibility)
Upsell animation sequences
License plate recognition for loyalty programs
✔ Beach Resorts
Tide/sunset time displays
Waterproof activity booking kiosks
UV index/safety alerts
✔ Airport Terminals
Multilingual wayfinding with flight updates
Duty-free shopping catalogs
Visa/immigration info portals
✔ Downtown Walkways
Public WiFi login portals
Crime reporting touchpoints
Air quality data visualization
✔ University Campuses
Emergency blue light stations
Event calendar + room booking
Sustainability dashboards
✔ Sports Arenas
Real-time stats + concession deals
Seat upgrade promotions
Augmented reality fan filters
✔ Music Festivals
Stage schedule updates
Social media photo upload stations
Lost & found reporting
✔ Bus/Train Stations
Real-time departure boards with touchscreen route planning
Emergency alert broadcasts (weather/security)
Contactless NFC ticket top-up stations
✔ EV Charging Hubs
Dynamic pricing/payment screens
Charging status animations
Nearby amenity directories
✔ Shopping Mall Entrances
AI-powered facial recognition ads (gender/age targeting)
Interactive store directories with AR navigation
Limited-time promo countdown timers
✔ Drive-Thru & QSR
Ultra-bright menu boards (2500nit visibility)
Upsell animation sequences
License plate recognition for loyalty programs
✔ Beach Resorts
Tide/sunset time displays
Waterproof activity booking kiosks
UV index/safety alerts
✔ Airport Terminals
Multilingual wayfinding with flight updates
Duty-free shopping catalogs
Visa/immigration info portals
✔ Downtown Walkways
Public WiFi login portals
Crime reporting touchpoints
Air quality data visualization
✔ University Campuses
Emergency blue light stations
Event calendar + room booking
Sustainability dashboards
✔ Sports Arenas
Real-time stats + concession deals
Seat upgrade promotions
Augmented reality fan filters
✔ Music Festivals
Stage schedule updates
Social media photo upload stations
Lost & found reporting
1. Q: What makes the 2500-nit display necessary for outdoor use?
A: A 2500-nit (candelas per square meter) screen brightness is essential for outdoor visibility. It ensures that the 4K content remains vibrant, high-contrast, and easily readable even under harsh, direct sunlight, overcoming glare that renders standard displays invisible.
2. Q: How is the "IP65" rating beneficial for an outdoor advertising screen?
A: The IP65 certification guarantees complete protection. The "6" means it is totally dust-tight, preventing internal damage from debris. The "5" means it can withstand low-pressure water jets from any direction, making it fully resistant to rain, snow, and cleaning with a hose, ensuring reliable operation in all weather.
3. Q: How does the integrated CMS software work for managing content?
A: The included Content Management System (CMS) is a cloud-based software platform. It allows you to remotely upload 4K videos and images, design playlists, schedule content by time/date, and deploy updates to one or hundreds of screens instantly via an internet connection (Wi-Fi/Ethernet/4G), all from a central dashboard.
4. Q: Is this a complete, ready-to-use system? What's included?
A: Yes, this is an all-in-one, turnkey solution. The "smart outdoor totem" includes: the ultra-bright 4K LCD screen, the built-in media player, the CMS software license, the IP65 waterproof and dustproof enclosure, and the integrated floor-standing mount. No need to source separate components.
5. Q: What type of video and content formats does the player support?
A: The smart media player supports a wide range of formats, including 4K UHD video files (like MP4, MOV), high-resolution images, PowerPoint files, PDFs, and even dynamic content like live data feeds (weather, social media) and HTML5 applications for interactive experiences.
6. Q: What are the installation requirements for this floor-standing totem?
A: It requires a stable, level surface (like concrete). For permanent installation and safety, we strongly recommend professional securing to a foundation to prevent tipping from wind or accidental impact. It needs access to a standard power outlet and an internet connection for the CMS.
7. Q: Can it operate in extreme hot or cold temperatures?
A: Yes. This totem is engineered for outdoor climates and includes an advanced thermal management system with internal heating and cooling components. This maintains the screen and electronics within a safe operating temperature range, ensuring performance from freezing winter conditions to intense summer heat.
8. Q: How secure is the system from hacking or unauthorized access?
A: Security is multi-layered. It includes password-protected device access, encrypted data transmission to/from the CMS, secure boot protocols, and the option for VPN or firewall configuration. The physical enclosure is also lockable to prevent tampering.
9. Q: What is the expected lifespan, and what maintenance is required?
A: Designed for 24/7 operation, the LED backlight typically has a lifespan of 50,000+ hours. Maintenance is minimal due to the sealed IP65 design. Primary tasks are periodic cleaning of the screen surface with recommended solutions and ensuring the ventilation vents (if external) are unobstructed.
10. Q: What warranty and technical support come with the product?
A: We offer a comprehensive standard warranty covering parts and labor for the display, player, and enclosure. Extended service plans are available. Our support includes remote diagnostics via the CMS, detailed setup guides, and access to technical specialists for troubleshooting.
1. Q: What makes the 2500-nit display necessary for outdoor use?
A: A 2500-nit (candelas per square meter) screen brightness is essential for outdoor visibility. It ensures that the 4K content remains vibrant, high-contrast, and easily readable even under harsh, direct sunlight, overcoming glare that renders standard displays invisible.
2. Q: How is the "IP65" rating beneficial for an outdoor advertising screen?
A: The IP65 certification guarantees complete protection. The "6" means it is totally dust-tight, preventing internal damage from debris. The "5" means it can withstand low-pressure water jets from any direction, making it fully resistant to rain, snow, and cleaning with a hose, ensuring reliable operation in all weather.
3. Q: How does the integrated CMS software work for managing content?
A: The included Content Management System (CMS) is a cloud-based software platform. It allows you to remotely upload 4K videos and images, design playlists, schedule content by time/date, and deploy updates to one or hundreds of screens instantly via an internet connection (Wi-Fi/Ethernet/4G), all from a central dashboard.
4. Q: Is this a complete, ready-to-use system? What's included?
A: Yes, this is an all-in-one, turnkey solution. The "smart outdoor totem" includes: the ultra-bright 4K LCD screen, the built-in media player, the CMS software license, the IP65 waterproof and dustproof enclosure, and the integrated floor-standing mount. No need to source separate components.
5. Q: What type of video and content formats does the player support?
A: The smart media player supports a wide range of formats, including 4K UHD video files (like MP4, MOV), high-resolution images, PowerPoint files, PDFs, and even dynamic content like live data feeds (weather, social media) and HTML5 applications for interactive experiences.
6. Q: What are the installation requirements for this floor-standing totem?
A: It requires a stable, level surface (like concrete). For permanent installation and safety, we strongly recommend professional securing to a foundation to prevent tipping from wind or accidental impact. It needs access to a standard power outlet and an internet connection for the CMS.
7. Q: Can it operate in extreme hot or cold temperatures?
A: Yes. This totem is engineered for outdoor climates and includes an advanced thermal management system with internal heating and cooling components. This maintains the screen and electronics within a safe operating temperature range, ensuring performance from freezing winter conditions to intense summer heat.
8. Q: How secure is the system from hacking or unauthorized access?
A: Security is multi-layered. It includes password-protected device access, encrypted data transmission to/from the CMS, secure boot protocols, and the option for VPN or firewall configuration. The physical enclosure is also lockable to prevent tampering.
9. Q: What is the expected lifespan, and what maintenance is required?
A: Designed for 24/7 operation, the LED backlight typically has a lifespan of 50,000+ hours. Maintenance is minimal due to the sealed IP65 design. Primary tasks are periodic cleaning of the screen surface with recommended solutions and ensuring the ventilation vents (if external) are unobstructed.
10. Q: What warranty and technical support come with the product?
A: We offer a comprehensive standard warranty covering parts and labor for the display, player, and enclosure. Extended service plans are available. Our support includes remote diagnostics via the CMS, detailed setup guides, and access to technical specialists for troubleshooting.
