Dinosaur D
| size: | |
|---|---|
| brightness: | |
| outdoor protect level: | |
| protective glass: | |
| brightness control: | |
| acoustic power: | |
| operation temparature: | |
| Availability: | |
| Quantity: | |
| Feature | Specification |
|---|---|
| Display | High-Brightness Sunlight Readable LCD, Anti-Glare Surface |
| Enclosure Rating | IP65/IP66 Waterproof & Dustproof |
| Installation | Secure Wall-Mount Design |
| Visibility | Optimal viewing angles for high-traffic pedestrian areas |
| Durability | Industrial-Grade Materials, Corrosion-Resistant Finish |
| Management | Cloud-Based Remote Content Scheduling & Updates |
| Typical Application | Bus Stations, Transit Shelters, Transportation Hubs |
| Feature | Specification |
|---|---|
| Display | High-Brightness Sunlight Readable LCD, Anti-Glare Surface |
| Enclosure Rating | IP65/IP66 Waterproof & Dustproof |
| Installation | Secure Wall-Mount Design |
| Visibility | Optimal viewing angles for high-traffic pedestrian areas |
| Durability | Industrial-Grade Materials, Corrosion-Resistant Finish |
| Management | Cloud-Based Remote Content Scheduling & Updates |
| Typical Application | Bus Stations, Transit Shelters, Transportation Hubs |
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface |  | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface | | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
Dynamic Bus/Train Schedule Displays
Sunlight-readable 2500+ nit screens for clear visibility
Weatherproof housing withstands rain, snow, and extreme temperatures
Instant WiFi/4G updates for delays and route changes
Touchscreen Station Maps
Anti-glare capacitive touch for passenger use
IP66-rated against dust and water splashes
ADA-compliant height and accessibility features
Emergency Alert Systems
High-contrast text for critical notifications
Tamper-proof construction for secure messaging
24/7 operation with automatic brightness adjustment
Digital Advertising Panels
Programmable ad spaces with scheduling software
Vivid colors maintained in direct sunlight
Remote content management via CMS
Multi-Function Information Hubs
Displays air quality, weather, and city news
USB charging ports integrated into totem design
Solar-powered options for eco-friendly deployment
Dynamic Bus/Train Schedule Displays
Sunlight-readable 2500+ nit screens for clear visibility
Weatherproof housing withstands rain, snow, and extreme temperatures
Instant WiFi/4G updates for delays and route changes
Touchscreen Station Maps
Anti-glare capacitive touch for passenger use
IP66-rated against dust and water splashes
ADA-compliant height and accessibility features
Emergency Alert Systems
High-contrast text for critical notifications
Tamper-proof construction for secure messaging
24/7 operation with automatic brightness adjustment
Digital Advertising Panels
Programmable ad spaces with scheduling software
Vivid colors maintained in direct sunlight
Remote content management via CMS
Multi-Function Information Hubs
Displays air quality, weather, and city news
USB charging ports integrated into totem design
Solar-powered options for eco-friendly deployment
1. Q: Is the display truly readable in direct sunlight at a bus station?
A: Absolutely. Our display features a high-brightness LCD panel (typically 1500-2500+ nits) and an anti-reflective, optically bonded screen. This technology ensures content like schedules, maps, and ads remains vivid and perfectly readable, even under harsh, direct sunlight—a common challenge at open-air bus stops.
2. Q: How is the display protected from constant outdoor exposure at a bus stop?
A: It is engineered as a fully sealed unit with a minimum IP65 rating. This certifies it is completely dust-tight (dustproof) and protected against low-pressure water jets from any direction (waterproof), making it resilient against driving rain, road spray, pollution, and the daily wear of a transit environment.
3. Q: How is the unit mounted on a bus station wall or shelter? What does installation involve?
A: The product features a secure, low-profile wall-mount design with universal VESA or custom bracket options. It is designed for efficient installation onto concrete, metal, or brick structures commonly found at stations. We provide a clear mounting template and hardware kit for straightforward installation by a qualified technician.
4. Q: What type of content can we show, and how do we update bus schedules remotely?
A: You can display real-time bus arrivals (via GTPS/RSS feed integration), static timetables, emergency alerts, news, and video ads. Updates are managed through our cloud-based content management system (CMS), allowing you to schedule and change content instantly from any web browser, eliminating the need for on-site visits.
5. Q: What is the expected lifespan and maintenance requirement for such an outdoor display?
A: Designed for 24/7 operation, the LCD panel has a long lifespan (50,000+ hours). The sealed IP65 enclosure requires virtually no internal maintenance. We recommend only periodic cleaning of the glass surface with a soft cloth. Its rugged construction ensures years of reliable service with minimal downtime.
6. Q: What are the power requirements, and does it have energy-saving features?
A: It operates on standard 100-240V AC. To save energy, it includes an auto-dimming sensor that intelligently adjusts screen brightness based on ambient light (e.g., lowering at night), reducing power consumption while maintaining perfect visibility.
7. Q: Can the display operate reliably in extreme temperatures?
A: Yes. The unit is built with industrial-grade components and an integrated thermal management system (heater and/or fan) to ensure stable performance within a wide operating temperature range (e.g., -20°C to +50°C / -4°F to 122°F), crucial for year-round outdoor use.
8. Q: Is the system compatible with real-time transit data feeds?
A: Yes. The display and its CMS support standard integration protocols (like GTFS-realtime, XML/JSON APIs) to connect with your existing transit information system, enabling the automatic display of live arrival times and service alerts.
9. Q: Does the purchase include software, and what kind of warranty and support is offered?
A: Yes, a full license for our cloud CMS software is included. The product comes with a standard 2-3 year warranty on parts and labor. We offer comprehensive technical support, with optional extended warranties and service plans available for critical transit infrastructure.
10. Q: Can the display withstand vandalism or accidental impact at a public bus station?
A: The unit is designed with public spaces in mind. It features a tempered safety glass front panel (often 6mm+ thick) that is highly impact and scratch-resistant. The robust, lockable metal enclosure also deters unauthorized access to internal components.
1. Q: Is the display truly readable in direct sunlight at a bus station?
A: Absolutely. Our display features a high-brightness LCD panel (typically 1500-2500+ nits) and an anti-reflective, optically bonded screen. This technology ensures content like schedules, maps, and ads remains vivid and perfectly readable, even under harsh, direct sunlight—a common challenge at open-air bus stops.
2. Q: How is the display protected from constant outdoor exposure at a bus stop?
A: It is engineered as a fully sealed unit with a minimum IP65 rating. This certifies it is completely dust-tight (dustproof) and protected against low-pressure water jets from any direction (waterproof), making it resilient against driving rain, road spray, pollution, and the daily wear of a transit environment.
3. Q: How is the unit mounted on a bus station wall or shelter? What does installation involve?
A: The product features a secure, low-profile wall-mount design with universal VESA or custom bracket options. It is designed for efficient installation onto concrete, metal, or brick structures commonly found at stations. We provide a clear mounting template and hardware kit for straightforward installation by a qualified technician.
4. Q: What type of content can we show, and how do we update bus schedules remotely?
A: You can display real-time bus arrivals (via GTPS/RSS feed integration), static timetables, emergency alerts, news, and video ads. Updates are managed through our cloud-based content management system (CMS), allowing you to schedule and change content instantly from any web browser, eliminating the need for on-site visits.
5. Q: What is the expected lifespan and maintenance requirement for such an outdoor display?
A: Designed for 24/7 operation, the LCD panel has a long lifespan (50,000+ hours). The sealed IP65 enclosure requires virtually no internal maintenance. We recommend only periodic cleaning of the glass surface with a soft cloth. Its rugged construction ensures years of reliable service with minimal downtime.
6. Q: What are the power requirements, and does it have energy-saving features?
A: It operates on standard 100-240V AC. To save energy, it includes an auto-dimming sensor that intelligently adjusts screen brightness based on ambient light (e.g., lowering at night), reducing power consumption while maintaining perfect visibility.
7. Q: Can the display operate reliably in extreme temperatures?
A: Yes. The unit is built with industrial-grade components and an integrated thermal management system (heater and/or fan) to ensure stable performance within a wide operating temperature range (e.g., -20°C to +50°C / -4°F to 122°F), crucial for year-round outdoor use.
8. Q: Is the system compatible with real-time transit data feeds?
A: Yes. The display and its CMS support standard integration protocols (like GTFS-realtime, XML/JSON APIs) to connect with your existing transit information system, enabling the automatic display of live arrival times and service alerts.
9. Q: Does the purchase include software, and what kind of warranty and support is offered?
A: Yes, a full license for our cloud CMS software is included. The product comes with a standard 2-3 year warranty on parts and labor. We offer comprehensive technical support, with optional extended warranties and service plans available for critical transit infrastructure.
10. Q: Can the display withstand vandalism or accidental impact at a public bus station?
A: The unit is designed with public spaces in mind. It features a tempered safety glass front panel (often 6mm+ thick) that is highly impact and scratch-resistant. The robust, lockable metal enclosure also deters unauthorized access to internal components.
