bus station subway park rain-proof high brightness outdoor video player totem advertising display waterproof wall mount signage

subway public spaces waterproof high brightness digital advertising video player signage lcd display 4K outdoor ip66 tv

bus station subway park rain-proof high brightness outdoor video player totem advertising display waterproof wall mount signage

Transform bustling transit hubs and public venues into dynamic communication points with our high-performance Outdoor Digital Signage Totem. Engineered specifically for demanding environments like bus stations, subways, and parks, this robust, wall-mount display delivers crisp, visible content rain or shine, ensuring your message is always seen.

Brand:
Dinosaur D

size:	32 43 49 55 65inch optional
brightness:	2500nit
outdoor protect level:	outdoor IP66
protective glass:	IK10 grade 5mm AG etched toughened glass
brightness control:	automatic photosensitive technology
acoustic power:	8 ohm 2×5W
operation temparature:	-30°C to +80°C
Availability:

Quantity:



Inquire Add to Basket

Designed for Durability & Maximum Visibility

Superior All-Weather Performance: Built with a rain-proof and waterproof (IP65-rated or higher) enclosure, this totem operates reliably in any weather, from drizzle to direct downpours, and is resistant to dust and humidity for 24/7 reliability.
High-Brightness 4K Display: Features an ultra-high-brightness LCD screen that combats direct sunlight and ambient glare. Combined with 4K Ultra HD resolution, it guarantees vibrant, legible, and captivating visuals for videos, advertisements, and information displays, even in bright outdoor conditions.
Integrated Media Player & CMS: Powered by a robust Android system with an integrated Content Management System (CMS). Schedule, manage, and update content remotely from anywhere. Easily deploy advertising campaigns, real-time transit information, public announcements, or community news.
Secure & Sleek Wall-Mount Design: The totem features a streamlined, wall-mount stand design that saves space and provides a secure, vandal-resistant installation for high-traffic areas. Its modern aesthetic enhances any public setting while housing all critical components in one protective unit..

screen panel specification	screen size	43 inch Industrial wide temperature OC panel
	display area	944.2mm*532.4mm
	product dimension	1007.6mm(L)88.9mm(W)595.8mm(H)
	protect level full	outdoor IP66
	resolution	1920*1080
	view angles	178°（H）/178°（V）
	Acoustic power	8 ohm 2×5W
	Contrast	1200：1
	Brightness	2500cd/㎡
	Protective glass	IK10 grade 5mm AG etched toughened glass
	Display Scale	16 : 9
	lifespan	50000h
	Casing color	black
	Brightness control	Automatic photosensitive technology
parameter of G+F touch screen	touch way	fingers
	effective touch recognition	≥5mm
	touch accuracy	±5mm
	touch point	10 point
	first point response time	≤10ms
interface
temperature control		Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work.
brightness control		The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight.
LED backlight		High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation.
protection	waterproof
	anti-electric leakage
	anti-thunder
	dust proof
	anti-explosion
	Anti-glare glass optional
	anti-rust
Fan cooling system	intelligent air cooling system for heat dissipation
	The fan speed regulating board can intelligently control the wind speed and save energy and electricity
	The LCD screen does not blacken at -30 °C to 80°C
	Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C)
	patented cooling system
	Ensure that the LCD screen is not blackened in direct sunlight
	Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk
	intelligent control fan wind speed
product test	IP66 test
	high temperature aging
	low temperature aging
	simulated sunlight test
	water proof test
surface treatment	wash	all parts of the sheet are cleaned in an acidic and alkaline manner
	anti-rust	Spray anti-rust paint
	spray	Spray outdoor powder (ensure 5-8 years do not drop paint, paint off)
shell	shell material	aluminum shell
Power	Input voltage	AC 100-305VAC
	power consumption	≤200W
	Operation temparature	-30°C to +80°C
	Operation humidity	5% to 90%

1. What makes this signage suitable for outdoor locations like bus stations and parks?
This unit combines a high-brightness display for clear visibility in direct sunlight with a fully rain-proof and waterproof enclosure (typically IP65 or higher), ensuring reliable 24/7 performance in all weather conditions. Its rugged build can withstand dust, moisture, and temperature variations common in transit and park settings.

2. How bright is the display, and can it be seen in direct sunlight?
The display features high brightness (usually 1500–2500 nits or higher), making it sunlight-readable. This ensures content remains vibrant and legible even in bright outdoor environments like subway entrances or open parks.

3. Can the totem be mounted on different types of walls or surfaces?
Yes. The wall-mount design includes a versatile mounting kit that allows secure installation on brick, concrete, metal frames, or other solid surfaces commonly found at bus stations, subway platforms, and park facilities.

4. How is content managed and updated?
Content is managed via a built-in Android-based video player with cloud-based CMS (Content Management System) support. You can remotely upload, schedule, and update ads, notices, or videos from any internet-connected device—no need for on-site visits.

5. Is the system capable of playing videos, images, and real-time information?
Yes. The media player supports various formats (video, images, PDF, HTML, etc.) and can integrate with data sources to display real-time information such as bus/train schedules, weather updates, or live news feeds.

6. What power supply is required, and how is cabling managed for outdoor use?
It operates on standard AC power (100–240V). The enclosure includes weatherproof cable glands to protect power and network connections from water and dust, ensuring safe outdoor installation.

7. Can the totem operate in extreme temperatures?
Yes. The device is designed with wide-temperature components and often includes heating/cooling systems to operate reliably in both freezing winters and hot summers, making it suitable for year-round outdoor use.

8. Is remote control or monitoring available?
Yes. Along with optional remote control for on-site adjustments, the CMS allows for remote monitoring of device status—including power, temperature, and content playback—enabling quick troubleshooting.

9. How durable and vandal-resistant is the unit?
The totem is built with reinforced aluminum or steel housing and tempered glass to resist impacts and vandalism. Optional lockable panels further protect internal components in public areas.

10. What after-sales support and warranty are offered?
We provide a standard 2–3 year warranty covering parts and labor. Technical support includes CMS training, installation guidance, and troubleshooting assistance to ensure smooth long-term operation.
