automatic brightness adjustment fan cool system player vertical display advertising display outdoor lcd screen waterproof digital totem

electronic lcd commercial ip65 free cms remote control stand touch screen advertising player 2500 nit display outdoor totem

automatic brightness adjustment fan cool system player vertical display advertising display outdoor lcd screen waterproof digital totem

Introducing the SmartVue Aura Pro – the next generation of intelligent outdoor digital advertising. Engineered for optimal performance and minimal maintenance, this fully integrated vertical display totem combines an auto-adjusting high-brightness LCD screen with an advanced adaptive cooling system, ensuring perfect visibility and reliable operation in any outdoor environment. Designed for 24/7 functionality, it delivers dynamic content with maximum impact while protecting itself from the elements and extreme conditions.

Brand:
Dinosaur D

size:	32 43 49 55 65 75 86 inch optional
tempered glass thickness:	6 mm tempered glass
resolution:	19201080 or 38402160
brightnees:	2500nit
protection level:	ip65
lifespan:	>50000 hours
Input voltage:	AC110-240V,50/60Hz
Availability:

Quantity:



Inquire Add to Basket

Core Innovation & Features

1. Intelligent Adaptive Brightness System

Light Sensor Technology: Automatically adjusts screen brightness (from 500 to 2500+ nits) based on real-time ambient light conditions.
Optimal Visibility & Efficiency: Ensures perfect readability at dawn, midday, and dusk while reducing power consumption during low-light hours.
Customizable Profiles: Pre-set modes (Standard, Energy-Saver, Maximum Impact) adaptable via CMS.

2. Advanced Thermal Management System

Dual-Zone Fan Cooling: Independently controlled fans regulate internal temperature for both the display panel and media player components.
Dust-Filtered & Sealed Design: IP65-rated fans maintain airflow while preventing water and dust ingress.
Overheat Protection: Automatically adjusts brightness or triggers cooling if critical temperatures are reached, ensuring component longevity.

3. All-Weather Ready & Durable Construction

Fully Waterproof Housing: IP65 certified enclosure withstands rain, snow, dust, and humidity.
Ruggedized Vertical Totem Design: Reinforced aluminum alloy structure with a weighted, anti-tip base.
Wide Temperature Operation: Functions flawlessly from -30°C to 55°C (-22°F to 131°F).

4. Integrated Professional Media Player

High-Performance Processor: Smooth 4K video playback and support for interactive content.
Remote Content Management: Schedule and update playlists via cloud-based CMS from anywhere.
Multi-Format Support: Compatible with video, images, HTML5, live data feeds, and APIs.

5. Ready-to-Deploy Vertical Advertising Solution

Pre-Integrated System: Display, player, cooling, and structural elements come fully assembled.
Simplified Installation: Just secure the base, connect to power and network, and begin broadcasting.
Low Maintenance Design: Self-regulating systems minimize the need for manual intervention.

outdoor-digital-signage_01 outdoor-digital-signage_02 outdoor-digital-signage_03 outdoor-digital-signage_04 outdoor-digital-signage_05 outdoor-digital-signage_06 outdoor-digital-signage_07 outdoor-digital-signage_08 outdoor-digital-signage_09 outdoor-digital-signage_10

structure	product dimension	690mm(L)400mm(W)1800mm(H)
	product net weight	80KG
	protect level	outdoor IP65
	casing color	black
	shell material	Hot-dip galvanized steel plate T=1.5 + outdoor double-sided spraying outdoor powder
	glass	6 mm tempered glass with light transmittance of more than 98%.
	Security	three-level door lock protection, hidden screw design, electronic magnetic lock
	dissipation system	The fan speed can be automatically adjusted according to the operating temperature, with heating function
	brightness control	Automatic photosensitive probe - automatically recognizes the surrounding environment and automatically adjusts the brightness of the screenm
	interface	USB, VGA output, HDMI output, AV input, SD card slot( supports up to 32GB), microphone, Clock battery holder
	camera optional	500W pixels
	loudspeaker	8Ω10W * 2
protection	waterproof	three layers of composite sealing rubber strip
	anti-electric leakage	3C certified brand leakage protector
	anti-thunder	unique lightning protection device
	dust proof	internal high air volume filter device
	anti-explosion	6MM tempered glass, explosion-proof, UV proof, low reflection, transmittance of more than 97%
	Anti-glare glass optional	6mm AR anti-reflection glass. AR coating is adopted
	anti-rust	galvanized steel sheet and outdoor double-sided spraying outdoor powder
screen panel specification	screen size	43 inch LCD screen panel
	display area	530mm*942mm
	resolution	1920*1080
	view angles	178°（H）/178°（V）
	Contrast	3500:1
	Brightness	2500cd/㎡
	color	16.7 M
	Display Scale	16 : 9
	lifespan	>50000 hours
	refresh rate	60Hz
	respond time	6ms
parameter of touch	touch way	fingers
	effective touch recognition	≥5mm
	touch accuracy	±5mm
	touch point	10 point
	first point response time	≤10ms
Fan cooling system	intelligent air cooling system for heat dissipation
	The fan speed regulating board can intelligently control the wind speed and save energy and electricity
	The LCD screen does not blacken at -40 °C to 55°C
	Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C)
	patented cooling system
	Ensure that the LCD screen is not blackened in direct sunlight
	Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk
	intelligent control fan wind speed
product test	IP65 test
	high temperature aging
	low temperature aging
	simulated sunlight test
	water proof test
surface treatment	wash	all parts of the sheet metal are cleaned in an acidic and alkaline manner
	anti-rust	Spray anti-rust paint
	spray	Spray outdoor powder (ensure 5-8 years do not drop paint, paint off)
Power	Input voltage	AC110-240V,50/60Hz
	power consumption	≤300w
working environment	temperature control	fan cooling (air cooling optional)
	operation temperature	-20°C to +50°C
	storage temperarure	-20°C to +60°C
	operation humidity	5% to 90%
quality standard	ISO9001
environmental protection standard	Meet international environmental standards
power management	Meets VESA DPMS standard

1. How does the automatic brightness adjustment work?
The display is equipped with a built-in ambient light sensor that continuously monitors surrounding light levels. It automatically adjusts the screen brightness from 500 to 2500 nits to ensure optimal visibility—reducing glare at night and maximizing brightness during midday sun—while also saving energy.

2. Why is an active fan cooling system important for an outdoor display?
Outdoor displays are exposed to direct sunlight and high temperatures, which can lead to overheating and reduced lifespan. The integrated IP65-rated fan cooling system actively regulates internal temperature, preventing thermal damage and ensuring stable performance 24/7.

3. Is the display truly waterproof, and what does IP65 mean?
Yes. The IP65 rating certifies that the display is fully protected against dust ingress and low-pressure water jets from any direction. This means it can withstand rain, snow, humidity, and dust without damage, making it suitable for permanent outdoor installation.

4. Can the display operate in extreme temperatures?
Yes. The display is designed with a wide operating temperature range, typically from -30°C to 55°C (-22°F to 131°F). The cooling system and temperature sensors help maintain a stable internal environment in both hot and cold climates.

5. How is content managed on the built-in media player?
The integrated media player supports remote content management via Wi-Fi, Ethernet, or optional 4G/LTE. You can upload, schedule, and update videos, images, and interactive content through a cloud-based CMS from anywhere.

6. What sizes are available for the vertical totem display?
Common sizes range from 42 inches to 75 inches (diagonal), with custom sizes available upon request. The vertical (portrait) orientation is ideal for pedestrian viewing and space-saving installations.

7. Does the automatic brightness feature work at night?
Yes. During nighttime or low-light conditions, the sensor will lower the brightness to a comfortable level, reducing light pollution, saving energy, and extending the display’s lifespan without compromising readability.

8. Is professional installation required?
While the totem is designed as an all-in-one unit with a pre-assembled stand, we recommend professional installation for permanent setups to ensure proper anchoring, electrical safety, and network connectivity—especially in public or high-wind areas.

9. Can the fan cooling system be controlled manually?
The cooling system operates automatically based on internal temperature sensors. However, you can monitor its status and receive alerts through the CMS. In most models, fan speed profiles can also be customized via the system settings.

10. What kind of content formats does the player support?
The player supports a wide range of formats, including MP4, AVI, JPEG, PNG, PDF, HTML5, and live data feeds (RSS, API integration). It is compatible with most digital signage software and allows for scheduled playlists and zone-based content layouts.
