Dinosaur D
| size: | |
|---|---|
| brightness: | |
| outdoor protect level: | |
| protective glass: | |
| brightness control: | |
| acoustic power: | |
| operation temparature: | |
| Availability: | |
| Quantity: | |
✔ 2500 Nits High Brightness – Crystal-clear visibility even in direct sunlight
✔ Military-Grade Durability – Full aluminum alloy casing for maximum protection
✔ Aviation-Grade Waterproof Plugs – Secure, dustproof, and corrosion-resistant interfaces
✔ IK10 Impact Resistance – 5mm toughened glass with anti-glare (AG) coating
✔ IP66 Weatherproof Rating – Resistant to rain, dust, and extreme temperatures
✔ Capacitive Mounting System – Easy and secure installation
✔ 2500 Nits High Brightness – Crystal-clear visibility even in direct sunlight
✔ Military-Grade Durability – Full aluminum alloy casing for maximum protection
✔ Aviation-Grade Waterproof Plugs – Secure, dustproof, and corrosion-resistant interfaces
✔ IK10 Impact Resistance – 5mm toughened glass with anti-glare (AG) coating
✔ IP66 Weatherproof Rating – Resistant to rain, dust, and extreme temperatures
✔ Capacitive Mounting System – Easy and secure installation
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface |  | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface | | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
Extreme Environment Installations
Offshore oil rig monitoring displays
Arctic/Antarctic research station information boards
Desert mining operation control panels
Tropical coastal resort wayfinding systems
Critical Infrastructure Applications
Nuclear power plant safety information displays
International airport runway status boards
Smart highway tunnel emergency message signs
High-speed rail platform information terminals
High-Security Facilities
Military base perimeter security displays
Prison complex information systems
Government building public alert screens
Bank outdoor ATM protection enclosures
Premium Commercial Spaces
Luxury automotive dealership showrooms
Five-star hotel outdoor digital concierge
High-end shopping mall facade displays
Golf course tournament scoreboards
Specialized Industrial Use
Food processing plant hygiene information boards
Pharmaceutical factory GMP compliance displays
Chemical plant hazardous area indicators
Data center operational status monitors
Extreme Environment Installations
Offshore oil rig monitoring displays
Arctic/Antarctic research station information boards
Desert mining operation control panels
Tropical coastal resort wayfinding systems
Critical Infrastructure Applications
Nuclear power plant safety information displays
International airport runway status boards
Smart highway tunnel emergency message signs
High-speed rail platform information terminals
High-Security Facilities
Military base perimeter security displays
Prison complex information systems
Government building public alert screens
Bank outdoor ATM protection enclosures
Premium Commercial Spaces
Luxury automotive dealership showrooms
Five-star hotel outdoor digital concierge
High-end shopping mall facade displays
Golf course tournament scoreboards
Specialized Industrial Use
Food processing plant hygiene information boards
Pharmaceutical factory GMP compliance displays
Chemical plant hazardous area indicators
Data center operational status monitors
1. Q: What are the material benefits of the all-aluminum alloy construction?
A: The full aluminum alloy chassis provides exceptional durability, corrosion resistance, and acts as an effective heat sink for thermal management. This ensures stable performance in harsh outdoor environments and significantly extends the product's lifespan.
2. Q: What is a "Capacitive Mounted Digital Player," and how is it different?
A: This refers to a high-precision, touch-sensitive mounting and control system. It often allows for features like capacitive touch buttons for control and can include smart mounting detection for security and automated power management, offering a more advanced user interface than physical buttons.
3. Q: What is the advantage of using aviation-grade plugs for the interfaces?
A: Aviation-grade plugs provide a superior, ruggedized connection. They are designed to withstand constant vibration, extreme temperatures, and moisture, ensuring a completely reliable and airtight connection, which is critical for maintaining the IP66 waterproof seal.
4. Q: How does the 5mm AG etched glass protect the display?
A: The 5mm Anti-Glare (AG) etched, toughened glass offers a dual layer of protection. It is highly impact-resistant (IK10 rated) against physical shocks and vandalism, while the AG etching diffuses ambient light to eliminate reflections and glare, guaranteeing clear visibility.
5. Q: Is the 2500 nits brightness sufficient for direct sunlight applications?
A: Absolutely. With a high brightness of 2500 nits, this display is specifically engineered to combat sun washout. Your content will remain vibrant, crisp, and easily readable even in the brightest direct sunlight conditions.
6. Q: What does the IP66 rating mean for overall protection?
A: The IP66 rating confirms that the entire machine is completely dust-tight and protected against powerful water jets. This makes it impervious to dust, rain, snow, and allows it to be cleaned with high-pressure water, ideal for permanent outdoor installation.
7. Q: Is a separate media player required to operate this screen?
A: No. This unit is an integrated "Advertising TV" with a built-in digital player. It can decode and play content directly from a USB drive or via its network connection, eliminating the need and cost for an external media player.
8. Q: How does the build quality contribute to the screen's longevity outdoors?
A: The combination of an aluminum alloy body and aviation-grade plugs creates a hermetically sealed, robust unit. This design resists corrosion from salt or pollution, dissipates heat efficiently to prevent internal damage, and maintains a waterproof seal over many years.
9. Q: Can this display be used in high-traffic, public areas?
A: Yes, it is ideal for such environments. The IK10 rating and toughened glass make it highly resistant to vandalism and accidental impacts, ensuring reliable operation in busy public spaces, transportation hubs, or retail areas.
10. Q: What makes this a "Commercial" or "Advertising" display compared to a consumer TV?
A: This display is built for 24/7 operation with commercial-grade components. Key differentiators include the high 2500-nit brightness, rugged aluminum and glass construction, IP66 waterproof rating, and integrated player—features not found in consumer TVs, which are not designed for continuous outdoor use.
1. Q: What are the material benefits of the all-aluminum alloy construction?
A: The full aluminum alloy chassis provides exceptional durability, corrosion resistance, and acts as an effective heat sink for thermal management. This ensures stable performance in harsh outdoor environments and significantly extends the product's lifespan.
2. Q: What is a "Capacitive Mounted Digital Player," and how is it different?
A: This refers to a high-precision, touch-sensitive mounting and control system. It often allows for features like capacitive touch buttons for control and can include smart mounting detection for security and automated power management, offering a more advanced user interface than physical buttons.
3. Q: What is the advantage of using aviation-grade plugs for the interfaces?
A: Aviation-grade plugs provide a superior, ruggedized connection. They are designed to withstand constant vibration, extreme temperatures, and moisture, ensuring a completely reliable and airtight connection, which is critical for maintaining the IP66 waterproof seal.
4. Q: How does the 5mm AG etched glass protect the display?
A: The 5mm Anti-Glare (AG) etched, toughened glass offers a dual layer of protection. It is highly impact-resistant (IK10 rated) against physical shocks and vandalism, while the AG etching diffuses ambient light to eliminate reflections and glare, guaranteeing clear visibility.
5. Q: Is the 2500 nits brightness sufficient for direct sunlight applications?
A: Absolutely. With a high brightness of 2500 nits, this display is specifically engineered to combat sun washout. Your content will remain vibrant, crisp, and easily readable even in the brightest direct sunlight conditions.
6. Q: What does the IP66 rating mean for overall protection?
A: The IP66 rating confirms that the entire machine is completely dust-tight and protected against powerful water jets. This makes it impervious to dust, rain, snow, and allows it to be cleaned with high-pressure water, ideal for permanent outdoor installation.
7. Q: Is a separate media player required to operate this screen?
A: No. This unit is an integrated "Advertising TV" with a built-in digital player. It can decode and play content directly from a USB drive or via its network connection, eliminating the need and cost for an external media player.
8. Q: How does the build quality contribute to the screen's longevity outdoors?
A: The combination of an aluminum alloy body and aviation-grade plugs creates a hermetically sealed, robust unit. This design resists corrosion from salt or pollution, dissipates heat efficiently to prevent internal damage, and maintains a waterproof seal over many years.
9. Q: Can this display be used in high-traffic, public areas?
A: Yes, it is ideal for such environments. The IK10 rating and toughened glass make it highly resistant to vandalism and accidental impacts, ensuring reliable operation in busy public spaces, transportation hubs, or retail areas.
10. Q: What makes this a "Commercial" or "Advertising" display compared to a consumer TV?
A: This display is built for 24/7 operation with commercial-grade components. Key differentiators include the high 2500-nit brightness, rugged aluminum and glass construction, IP66 waterproof rating, and integrated player—features not found in consumer TVs, which are not designed for continuous outdoor use.
