43 55 65 75inch Ip66 Optical Bonding Super Thin All Weather Proof Digital Signage and Displays Outdoor Tv Waterproof

43 55 65 75inch Ip66 Optical Bonding Super Thin All Weather Proof Digital Signage and Displays Outdoor Tv Waterproof

Created for perfection. LuminOutdoor Elite redefines outdoor entertainment. Not only can it easily withstand rain, dust and extreme temperatures, but also with its 4K HDR ultra-clear picture quality and 3000 nits peak brightness, you can enjoy an unparalleled visual feast even in the strong afternoon light. Whether it's a poolside party or a terrace movie night, it is a symbol of your taste.

Brand:
Dinosaur D

size:	32 43 49 55 65inch optional
brightness:	2500nit
outdoor protect level:	outdoor IP66
protective glass:	IK10 grade 5mm AG etched toughened glass
brightness control:	automatic photosensitive technology
acoustic power:	8 ohm 2×5W
operation temparature:	-30°C to +80°C
Availability:

Quantity:



Inquire Add to Basket

In your backyard, create endless possibilities

LuminOutdoor Elite is not merely a television; it is a complete outdoor entertainment center. We understand the demanding nature of outdoor environments, and therefore have adopted top-notch technology both internally and externally to ensure stability and picture quality without any compromise.

Core Strengths:

Sturdy design resistant to environmental conditions: Achieves IP66 protection level, completely preventing dust from entering, and can withstand powerful water jets from all directions, easily coping with sun exposure and rain. The shell has been specially treated, being corrosion-resistant and UV-resistant.

The brilliant picture quality under the sun: A 3000 nits high-brightness screen and HDR technology effectively resist direct sunlight, presenting clear picture details and rich colors, eliminating gloom and reflections.

Immersive audio experience: Equipped with a powerful multi-speaker audio system, it offers a surround sound effect. Some models are compatible with Dolby Atmos, allowing you to enjoy cinema-level sound even when outdoors.

Intelligent Ecology and Convenient Control: Equipped with popular smart TV systems (such as Google TV), you can easily access a vast amount of streaming media content. You can also control it through a voice assistant or the accompanying waterproof remote control.

Technical Specifications:

Screen size: 55", 65", 75" (optional)

Resolution: 4K Ultra HD (3840x2160)

Brightness: 3000 Nits

Protection level: IP6

Operating temperature: -4°F to 122°F (-20°C to 50°C)

Intelligent System: Google TV

Main interfaces: HDMI, USB, Optical Audio

Outdoor-Display-_01 Outdoor-Display-_02 Outdoor-Display-_03 Outdoor-Display-_04 Outdoor-Display-_05 Outdoor-Display-_06 Outdoor-Display-_07 Outdoor-Display-_08 Outdoor-Display-_09 Outdoor-Display-_10

screen panel specification	screen size	43 inch Industrial wide temperature OC panel
	display area	944.2mm*532.4mm
	product dimension	1007.6mm(L)88.9mm(W)595.8mm(H)
	protect level full	outdoor IP66
	resolution	1920*1080
	view angles	178°（H）/178°（V）
	Acoustic power	8 ohm 2×5W
	Contrast	1200：1
	Brightness	2500cd/㎡
	Protective glass	IK10 grade 5mm AG etched toughened glass
	Display Scale	16 : 9
	lifespan	50000h
	Casing color	black
	Brightness control	Automatic photosensitive technology
parameter of G+F touch screen	touch way	fingers
	effective touch recognition	≥5mm
	touch accuracy	±5mm
	touch point	10 point
	first point response time	≤10ms
interface
temperature control		Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work.
brightness control		The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight.
LED backlight		High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation.
protection	waterproof
	anti-electric leakage
	anti-thunder
	dust proof
	anti-explosion
	Anti-glare glass optional
	anti-rust
Fan cooling system	intelligent air cooling system for heat dissipation
	The fan speed regulating board can intelligently control the wind speed and save energy and electricity
	The LCD screen does not blacken at -30 °C to 80°C
	Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C)
	patented cooling system
	Ensure that the LCD screen is not blackened in direct sunlight
	Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk
	intelligent control fan wind speed
product test	IP66 test
	high temperature aging
	low temperature aging
	simulated sunlight test
	water proof test
surface treatment	wash	all parts of the sheet are cleaned in an acidic and alkaline manner
	anti-rust	Spray anti-rust paint
	spray	Spray outdoor powder (ensure 5-8 years do not drop paint, paint off)
shell	shell material	aluminum shell
Power	Input voltage	AC 100-305VAC
	power consumption	≤200W
	Operation temparature	-30°C to +80°C
	Operation humidity	5% to 90%

1. Q: What is the purpose of the built-in photosensitive head?
A: The built-in photosensitive head enables Intelligent Photosensitive Technology. It automatically detects the ambient light levels in the environment and adjusts the screen's brightness in real-time. This ensures optimal visibility while saving energy and improving the lifespan of the display.

2. Q: How do I manage and update the content on the screen?
A: The display is supported by a Smart Free CMS (Content Management System) software. This allows you to easily schedule, manage, and update your advertising content remotely from a central computer or network.

3. Q: Is a separate media player required for this screen?
A: No, a separate player is not required. The product is an "LCD Advertising Player," meaning it has a built-in system for playing content directly, simplifying your setup and reducing external hardware.

4. Q: Can I control the screen remotely?
A: Yes, the display supports Wireless Remote Control. This allows you to turn the screen on/off, adjust basic settings, or switch inputs without needing physical access to the unit.

5. Q: How durable is the screen against physical damage and reflections?
A: The screen is protected by a 5mm thick, AG (Anti-Glare) etched, toughened glass with an IK10 rating. This makes it highly resistant to impacts, vandalism, and scratches, while the AG coating diffuses light to minimize glare.

6. Q: What sizes are available for this high-brightness outdoor display?
A: The display is available in multiple sizes to fit various installation needs, including 32, 43, 49, and 55 inches.

7. Q: Is the 2500 nits brightness sufficient for outdoor use?
A: Yes, 2500 nits is considered high brightness and is perfectly suited for outdoor environments. It ensures that your content remains vivid, clear, and easily readable even in direct sunlight.

8. Q: What does the IP66 rating guarantee?
A: The IP66 rating certifies that the display is completely "dust-tight" and protected against powerful jets of water from any direction. This high level of waterproofing makes it reliable for outdoor use in all weather conditions, including heavy rain.

9. Q: Is the CMS software really free? Are there any hidden costs?
A: Yes, the product includes "Smart free CMS software support." This typically means the basic software license and core functionality for content management are provided at no additional cost.

10. Q: Can this display be used in a very cold or hot climate?
A: While the specific temperature range isn't listed in this set of features, a display with an IP66 rating and built for outdoor use is typically engineered to withstand a wide range of temperatures. For the exact operational and storage temperature specifications, please consult the product's detailed datasheet.
