✔ 2500 Nits High Brightness – Perfect visibility in direct sunlight
✔ Military-Grade Protection – Full aluminum alloy body with aviation-grade waterproof plugs
✔ IK10 Impact Resistance – 5mm AG etched toughened glass (scratch & vandal-proof)
✔ IP66 Waterproof – Dustproof, rainproof, and corrosion-resistant
✔ Wall-Mount Design – Easy installation for various outdoor applications
✔ Factory Direct Pricing – High quality at competitive wholesale rates
✔ 2500 Nits High Brightness – Perfect visibility in direct sunlight
✔ Military-Grade Protection – Full aluminum alloy body with aviation-grade waterproof plugs
✔ IK10 Impact Resistance – 5mm AG etched toughened glass (scratch & vandal-proof)
✔ IP66 Waterproof – Dustproof, rainproof, and corrosion-resistant
✔ Wall-Mount Design – Easy installation for various outdoor applications
✔ Factory Direct Pricing – High quality at competitive wholesale rates
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface |  | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
| screen panel specification | screen size | 43 inch Industrial wide temperature OC panel | |||||||||
| display area | 944.2mm*532.4mm | ||||||||||
| product dimension | 1007.6mm(L)*88.9mm(W)*595.8mm(H) | ||||||||||
| protect level full | outdoor IP66 | ||||||||||
| resolution | 1920*1080 | ||||||||||
| view angles | 178°（H）/178°（V） | ||||||||||
| Acoustic power | 8 ohm 2×5W | ||||||||||
| Contrast | 1200：1 | ||||||||||
| Brightness | 2500cd/㎡ | ||||||||||
| Protective glass | IK10 grade 5mm AG etched toughened glass | ||||||||||
| Display Scale | 16 : 9 | ||||||||||
| lifespan | 50000h | ||||||||||
| Casing color | black | ||||||||||
| Brightness control | Automatic photosensitive technology | ||||||||||
| parameter of G+F touch screen | touch way | fingers | |||||||||
| effective touch recognition | ≥5mm | ||||||||||
| touch accuracy | ±5mm | ||||||||||
| touch point | 10 point | ||||||||||
| first point response time | ≤10ms | ||||||||||
| interface | | ||||||||||
| temperature control | | Built-in temperature probe sensing equipment, effectively identify the temperature change in the machine. The temperature change can be displayed on the PCB LED. Intelligent control of the wind speed of the fan can be adjusted intelligently according to the temperature change. The temperature control display has a fan monitoring indicator, which can be monitored throughout the work. | |||||||||
| brightness control | | The built-in sensor can automatically adjust the brightness of the LCD display screen according to the the outdoor light. LED backlight control and sensing core technology can improve the light transmission, effectively identify, control, and adjust the brightness of LED backlight. | |||||||||
| LED backlight | | High brightness LCD screen, brightness reaches 3000 cd/m2. The LED backlight is used, with lifespan of over 50,000 hours, high environmental protection and energy saving dynamic contrast, and clear display picture. Combined with the heat dissipation scheme precise temperature control, the display 7*24 hours working brightness without attenuation. | |||||||||
| protection | waterproof | ||||||||||
| anti-electric leakage | |||||||||||
| anti-thunder | |||||||||||
| dust proof | |||||||||||
| anti-explosion | |||||||||||
| Anti-glare glass optional | |||||||||||
| anti-rust | |||||||||||
| Fan cooling system | intelligent air cooling system for heat dissipation | ||||||||||
| The fan speed regulating board can intelligently control the wind speed and save energy and electricity | |||||||||||
| The LCD screen does not blacken at -30 °C to 80°C | |||||||||||
| Self-dynamic temperature to ensure that the internal temperature of the machine is within the range of 5°C to 25°C (to ensure that the internal temperature of the machine is between -5°C and 55°C) | |||||||||||
| patented cooling system | |||||||||||
| Ensure that the LCD screen is not blackened in direct sunlight | |||||||||||
| Built-in temperature probe sensing equipment, effectively identify the temperature change in the kiosk | |||||||||||
| intelligent control fan wind speed | |||||||||||
| product test | IP66 test | ||||||||||
| high temperature aging | |||||||||||
| low temperature aging | |||||||||||
| simulated sunlight test | |||||||||||
| water proof test | |||||||||||
| surface treatment | wash | all parts of the sheet are cleaned in an acidic and alkaline manner | |||||||||
| anti-rust | Spray anti-rust paint | ||||||||||
| spray | Spray outdoor powder (ensure 5-8 years do not drop paint, paint off) | ||||||||||
| shell | shell material | aluminum shell | |||||||||
| Power | Input voltage | AC 100-305VAC | |||||||||
| power consumption | ≤200W | ||||||||||
| Operation temparature | -30°C to +80°C | ||||||||||
| Operation humidity | 5% to 90% | ||||||||||
Extreme Environment Installations
Desert mining operation control panels
Oil refinery process monitoring displays
Steel mill production line information boards
Foundry temperature status indicators
Smart City Infrastructure
Highway electronic toll collection displays
Urban heat island monitoring stations
Solar farm operation status boards
Waste management system information kiosks
Transportation Systems
Railway switch heating monitoring displays
Airport tarmac equipment status screens
Underground parking guidance systems
Electric vehicle charging station dashboards
Industrial Facilities
Power plant turbine monitoring displays
Chemical plant process control screens
Food processing plant hygiene stations
Pharmaceutical warehouse condition monitors
Public Safety Applications
Forest fire warning system displays
Flood monitoring station information boards
Earthquake early warning terminals
Nuclear facility perimeter status screens
Extreme Environment Installations
Desert mining operation control panels
Oil refinery process monitoring displays
Steel mill production line information boards
Foundry temperature status indicators
Smart City Infrastructure
Highway electronic toll collection displays
Urban heat island monitoring stations
Solar farm operation status boards
Waste management system information kiosks
Transportation Systems
Railway switch heating monitoring displays
Airport tarmac equipment status screens
Underground parking guidance systems
Electric vehicle charging station dashboards
Industrial Facilities
Power plant turbine monitoring displays
Chemical plant process control screens
Food processing plant hygiene stations
Pharmaceutical warehouse condition monitors
Public Safety Applications
Forest fire warning system displays
Flood monitoring station information boards
Earthquake early warning terminals
Nuclear facility perimeter status screens
1. Q: What does "sunlight readable" mean, and how is it achieved?
A: "Sunlight readable" means the screen remains perfectly clear and vibrant even in direct sunlight. This is achieved through a combination of a high-brightness LCD panel (typically 2000+ nits) and an industrial-grade anti-glare glass that diffuses light to eliminate reflections.
2. Q: How does the intelligent photosensitive technology work?
A: The built-in photosensitive head continuously measures the ambient light. The intelligent system then automatically adjusts the screen's brightness in real-time. This ensures optimal visibility in all conditions—from bright daylight to night—while also saving energy and reducing wear on the LEDs.
3. Q: What is the benefit of the high-temperature resistant industrial LCD glass?
A: This specialized glass is engineered to withstand prolonged exposure to high heat from both the sun and the display's own internal components. This prevents discoloration, delamination, and failure, ensuring long-term reliability and image stability in harsh outdoor or industrial settings.
4. Q: Can this display be used as a freestanding kiosk or totem?
A: Yes. The product description includes a "monitor stand totem," indicating it is designed for versatile mounting. It can be deployed as a freestanding digital totem in lobbies or public spaces, or alternatively mounted on a wall using a compatible bracket.
5. Q: What level of weather and dust protection does the IP66 rating provide?
A: The IP66 rating guarantees complete protection. The "6" means it is totally dust-tight, and the second "6" means it can withstand powerful jets of water from any direction. This makes it impervious to rain, snow, dust storms, and can even be cleaned with high-pressure hoses.
6. Q: Is this unit just a display, or does it include a media player?
A: As an "LCD TV" and "digital signage display," it is typically an all-in-one solution with a built-in media player. This allows it to play content directly from a USB drive or network source without requiring an external computer or player, simplifying the setup.
7. Q: What environments is this screen designed for?
A: It is built for demanding environments, both outdoors and indoors. Its key features—sunlight readability, IP66 waterproofing, and high-temperature resistance—make it ideal for outdoor advertising, industrial control rooms, transportation hubs, and public kiosks exposed to the elements.
8. Q: Why is industrial-grade glass important for an outdoor screen?
A: Standard glass cannot handle the thermal stress and physical hazards of outdoor use. Industrial LCD glass is chemically strengthened and laminated to be more resistant to impacts, extreme temperature fluctuations, UV radiation, and moisture, ensuring a longer operational life.
9. Q: Does the automatic brightness control work at night?
A: Yes, that is a key advantage. The intelligent photosensitive technology will dim the screen in low-light or dark conditions. This prevents the display from being uncomfortably bright at night, reduces power consumption, and minimizes light pollution.
10. Q: What is the main advantage of this display over a standard commercial TV for outdoor use?
A: A standard TV would fail quickly outdoors. This display is purpose-built with a sunlight-readable panel, weatherproof IP66 sealing, temperature-resistant materials, and intelligent sensors. It is a durable, industrial-grade tool designed for 24/7 reliability in conditions that would destroy a consumer-grade product.
1. Q: What does "sunlight readable" mean, and how is it achieved?
A: "Sunlight readable" means the screen remains perfectly clear and vibrant even in direct sunlight. This is achieved through a combination of a high-brightness LCD panel (typically 2000+ nits) and an industrial-grade anti-glare glass that diffuses light to eliminate reflections.
2. Q: How does the intelligent photosensitive technology work?
A: The built-in photosensitive head continuously measures the ambient light. The intelligent system then automatically adjusts the screen's brightness in real-time. This ensures optimal visibility in all conditions—from bright daylight to night—while also saving energy and reducing wear on the LEDs.
3. Q: What is the benefit of the high-temperature resistant industrial LCD glass?
A: This specialized glass is engineered to withstand prolonged exposure to high heat from both the sun and the display's own internal components. This prevents discoloration, delamination, and failure, ensuring long-term reliability and image stability in harsh outdoor or industrial settings.
4. Q: Can this display be used as a freestanding kiosk or totem?
A: Yes. The product description includes a "monitor stand totem," indicating it is designed for versatile mounting. It can be deployed as a freestanding digital totem in lobbies or public spaces, or alternatively mounted on a wall using a compatible bracket.
5. Q: What level of weather and dust protection does the IP66 rating provide?
A: The IP66 rating guarantees complete protection. The "6" means it is totally dust-tight, and the second "6" means it can withstand powerful jets of water from any direction. This makes it impervious to rain, snow, dust storms, and can even be cleaned with high-pressure hoses.
6. Q: Is this unit just a display, or does it include a media player?
A: As an "LCD TV" and "digital signage display," it is typically an all-in-one solution with a built-in media player. This allows it to play content directly from a USB drive or network source without requiring an external computer or player, simplifying the setup.
7. Q: What environments is this screen designed for?
A: It is built for demanding environments, both outdoors and indoors. Its key features—sunlight readability, IP66 waterproofing, and high-temperature resistance—make it ideal for outdoor advertising, industrial control rooms, transportation hubs, and public kiosks exposed to the elements.
8. Q: Why is industrial-grade glass important for an outdoor screen?
A: Standard glass cannot handle the thermal stress and physical hazards of outdoor use. Industrial LCD glass is chemically strengthened and laminated to be more resistant to impacts, extreme temperature fluctuations, UV radiation, and moisture, ensuring a longer operational life.
9. Q: Does the automatic brightness control work at night?
A: Yes, that is a key advantage. The intelligent photosensitive technology will dim the screen in low-light or dark conditions. This prevents the display from being uncomfortably bright at night, reduces power consumption, and minimizes light pollution.
10. Q: What is the main advantage of this display over a standard commercial TV for outdoor use?
A: A standard TV would fail quickly outdoors. This display is purpose-built with a sunlight-readable panel, weatherproof IP66 sealing, temperature-resistant materials, and intelligent sensors. It is a durable, industrial-grade tool designed for 24/7 reliability in conditions that would destroy a consumer-grade product.
